Açıklama
Model Çiğ Noktası Kapasite m³/dk Bağlantı Boy mm En mm Yükseklik mm
AKDAB 33 -40 0.03 R 1 ¼ 600 400 400
AKDAB 133 -40 0.14 R 1 ¼ 1100 400 400
AKDAB 267 -40 0.28 R 1 ¼ 1700 450 400
AKDAB 400 -40 0.43 R 1 ¼ 1700 450 400
AKDAB 533 -40 0.57 R 1 ¼ 1700 450 400
AKDAB 800 -40 0.87 R 1 ¼ 1700 450 400
AKDAB 1000 -40 1.08 R 1 ½ 1700 450 400
AKDAB 1200 -40 1.30 R 1 ½ 1700 450 400
AKDAB 1600 -40 1.73 R 1 ½ 1700 450 400
AKDAB 2000 -40 2.17 R 1 ¾ 1900 450 400
AKDAB 2667 -40 2.90 R 1 ¾ 1900 450 400
AKDAB 3200 -40 3.47 R 1 1900 650 600
AKDAB 4000 -40 4.34 R 1 1900 650 600
AKDAB 5000 -40 5.43 R 1 ½ 1900 650 600
AKDAB 6000 -40 6.52 R 1 ½ 1900 650 600
AKDAB 7000 -40 7.61 R 1 ½ 2100 1100 800
AKDAB 8000 -40 8.69 R 1 ½ 2100 1100 800
AKDAB 9500 -40 10.33 R 1 ½ 2100 1100 800
AKDAB 10500 -40 11.41 R 2 2100 1100 800
AKDAB 12000 -40 13.04 R 2 2100 1100 800
AKDAB 16000 -40 17.39 R 2 2100 1100 800
AKDAB 20000 -40 21.74 DN 80 2100 1100 800
AKDAB 25000 -40 27.18 DN 80 2600 1100 800
AKDAB 30000 -40 32.62 DN 80 2600 1200 800
AKDAB 40000 -40 43.49 DN 100 2950 1300 1100
AKDAB 50000 -40 54.37 DN 100 2950 1500 1250
AKDAB 75000 -40 81.55 DN 125 2950 1800 1450
